Rywire LHD EG/DC B Series OEM Replacement Engine Harness

Rywire LHD EG/DC B Series OEM Replacement Engine Harness

  • OEM Replacement Engine Harness
  • Compatible with EG & DC Chassis
  • Made for Left Hand Drive (LHD)
  • Uses OE Style Connectors
  • Description
  • Vehicle Fitment
  • Technical Data
  • The new Rywire B Series OEM Replacement Engine Harness is now available for the EG/DC chassis in LEFT HAND DRIVE orientation. This wire harness is made to replace the engine bay harness in your 92-95 USA model Civics with B series (96-01)swaps and 94-01 Integra's (all models). Think of this harness as an OEM replacement USA model Type R harness. Ideal for single-runner type intake manifolds.

    Please note, that if you are not using the crankshaft sensor or knock sensor please leave those disconnected. You will notice a 3-wire shock tower connector is also not needed for all applications. You will also need to use your original donor "power cap" connector from your factory harness. There will be no power to your harness without this cap connector. Easy to identify the 8-position cap with the yellow with black stripe wires running to it.

    All connectors and materials are new. Each connector is crimped with pneumatic heads to ensure an OEM crimp every time. All heavy interference circuits are protected and grounded with proper wire covering. Our engine harnesses are 100% quality tested pin to pin; And resistance checked to ensure no voltage fluctuations.
  • 1992-1995 Honda Civic
    1994-2001 Acura Integra
  • Includes These Connectors:
    Obd2 96-01 Distributor connectors
    Obd2 96-01 Alternator connector
    Obd2 96-01 Injector connectors
    92-01 spec Air temp sensor (B series Type R top of intake manifold)
    92-01 Oil pressure sending unit
    Alternator charge cable to fuse box
    96+ spec crank shaft sensor (B series 2 wire oil pump mounted crank sensor) Obd1 ecu cars do not need this
    92-01 knock sensor
    92-01 Idle motor
    92-01 TPS
    92-01 Map sensor
    92-01 Purge solenoid (B series Type R firewall side of intake manifold)
    92-01 Vtec solenoid
    92-01 Vtec solenoid pressure sensor
    92-01 Reverse light switch
    92-01 Water temp sensor
    92-01 Water temp sending unit
    92-01 Starter motor
    92-01 Fan switch
    92-01 Thermostat ground ring
    92-01 4-wire O2 sensor
    92-01 Speed sensor
    92-01 passenger side shock tower plugs
    92-01 Drivers side shock tower plugs
